Spectrum PC/PTFE Natural 1.75mm 750g

High temperature resistance and abrasion resistance

Spectrum PC/PTFE is an advanced polycarbonate-based (PC) composite filament with the addition of PTFE commonly known as teflon. The high demand and limited availability of additive manufacturing materials with very good mechanical properties, with particular emphasis on high abrasion resistance, led to the efforts aimed to combine great properties of PC and PTFE. Polycarbonate provides high mechanical resistance and PTFE complements other properties by reducing wear and friction.

The applied modifications ensure improved thermal stability of printed parts, increased electrical insulation and higher chemical and water resistance. Due to its properties, Spectrum PC/PTFE filament is a material for a wide range of industrial applications. Materials printed using the PC/PTFE filament can be machined for a perfectly smooth surface. The use of this type of material makes it possible to manufacture parts with relatively complex geometries while maintaining relatively high dimensional accuracy.

To attain the very attractive properties of Spectrum PC/PTFE, as regards the technical aspects, you need to follow the basic storage rules for such materials (in a dry and dark place with humidity below 15%). To obtain the best parameters of the printed object possible, it is recommended to dry the material prior to work.

Tip: It is recommended to print using a heated chamber.

Material characteristics

• low processing shrinkage (linear) approx. 0.6 %
• heat deflection temperature (HDT)- 140 °C
• Vicat softening point – 145 °C
• flammability rating UL 94 (3.0 mm) – V1
• electrical resistance 1E12 Ohm
• static coefficient of friction – 0.18
• dynamic coefficient of friction – 0.14
• high abrasion resistance
• high mechanical strength
• very strong lamination of layers

Applications

• manufacturing low friction parts
• manufacturing parts providing heat, electrical and thermal insulation
• manufacturing low-load gears and transmission elements
• manufacturing tools used to assemble components during the production process of
• end-use parts
• functional prototyping

VERIFY YOUR SPOOL - the most precise quality control system on  the market

Filament for 3D printers is manufactured by the method of free extrusion, which is one of the most difficult processing techniques by extrusion, due to the particularly significant impact of process parameters on product dimensions and material homogenization.

During the production each 1mm of Spectrum Filament is being continuously measured in 2 axes with ±0.8µm accuracy, which allow obtaining a high-quality final product. To prove this, Spectrum Filaments, as one of the few manufacturers in the world, has introduced the possibility of online presentation, individually for each manufactured spool:

• the course of diameter on the entire length of the spool,
• mean diameter,
• ovality,
• standard deviation

Precise survey guarantees that Spectrum Filaments products meet rigorous market requirements.
